Single Channel High intentione lsolation Modules

Jansum ut professio Singuli Channel High Voltage lsolation Modulorum opificem, quiescere potes alta intentione lsolationis Modulae ex officina nostra emere, et tibi optimam post venditionem operae et opportunam traditionem tibi offeremus. Inhaerentes studio perfectae qualitatis productorum, ut Excelsa intentione lsolationis Moduli a multis clientibus satisfactum sit. H06C01SH stat pro 3000Vac.

Exemplar: H06C01SH

Model:H06C01SH

Mitte Inquisitionem

PDF Download

depictio producti

Find ingens electioSingle Channel High intentione lsolation Modulesex China apud JASN. Praebere professionalem post-venditionem servitium et pretium ius, cooperationem expectamus.

Single Channel High intentione lsolation Modules

Feature

Parere cum RoHS requisitis.
Temperatura operans range: -40â ad +125â.
Repono temperatus range: -40â ad +125â.

Electrical Specifications @ 25â

OCL:	Pri: 150uH Min. @100KHz/0.1V
Hi-pot :	4730VDC 0.5mA 2Sec
Vertit Rationem:	1CT:1CT±2%
LK:	Pri: 0.5uH Max @100KHz/0.1V
DCR:	Pri : 0.55ohm Max
DCR:	Sec : 0.85ohm Max
CWW:	28pF Max
Damnum insertio:	4MHz: -0.25dB Max
Redi damnum:	4MHz: -20dB Min
CMRR:	1-10MHz: -35dB Min
CMRR:	10-100MHz: -20dB Min
